Private Treaty Sale | Stellantis | ERFURT EMP 2000 Special Press
Lot 1:ERFURT EMP 2000 Mechanical Link-Drive Press
Mechanical Press
Pressure total: 2.000 ton
Ram stroke: 1.000 mm
Slide adjustment: 150 mm
Shut height (stroke down, adjustment up): 1.500 mm
Free frontal opening L-R: 4600 mm
Table surface area: 4.500 x 2.400 mm
Slide area: 4.500 x 2.400 mm
Tax Rate on Hammer Price: 20%
Tax Rate on Charges: 20%
Description
Year of Manufacture: 1999
Pressure total: 2.000 ton
Ram stroke: 1.000 mm
Slide adjustment: 150 mm
Shut height (stroke down, adjustment up): 1.500 mm
Free frontal opening L-R: 4600 mm
Table surface area: 4.500 x 2.400 mm
Slide area: 4.500 x 2.400 mm
Die cushion capacity in the table: 160 - 400 ton
Die cushion stroke: 0 - 300 mm
Die cushion pad area: 3600 x 1700 mm
The number of strokes: 6 - 18 s.p.m.
Die weight at the ram max.: 25.000 kg
Table height over the Floor: 385 mm
Weight of Link-Drive Crown: 72 ton
Height over the Floor, approx.: 9.600 mm
Weight of machine, approx.: 470 tonnes
(The bed cushion, electrics and hydraulics were overhauled c. 6 years ago). These works were undertaken by SCHULER - MÜLLER WEINGARTEN)
More details are available upon request.
Press sales in association with Pressen Haas.
VIDEO: https://youtu.be/fHL1uaSFsas
